Lock nuts with integral locking device
Drawing
Datasheet
| Lock Nuts | Dimensions | Weight | |||||
| G | d1 | d3 | B | b2 | h | ||
| – | mm | mm | mm | mm | mm | mm | kg |
| KMK 0 | M 10x0,75 | 16 | 20 | 9 | 3 | 2 | 0,016 |
| KMK 1 | M 12x1 | 18 | 22 | 9 | 3 | 2 | 0,018 |
| KMK 2 | M 15x1 | 21 | 25 | 9 | 4 | 2 | 0,021 |
| KMK 3 | M 17x1 | 24 | 28 | 9 | 4 | 2 | 0,027 |
| KMK 4 | M 20x1 | 28 | 32 | 9 | 4 | 2 | 0,030 |
| KMK 5 | M 25x1,5 | 34 | 38 | 9 | 5 | 2 | 0,030 |
| KMK 6 | M 30x1,5 | 41 | 45 | 9 | 5 | 2 | 0,060 |
| KMK 7 | M 35x1,5 | 48 | 52 | 9 | 5 | 2 | 0,070 |
| KMK 8 | M 40x1,5 | 53 | 58 | 11 | 6 | 2,5 | 0,11 |
| KMK 9 | M 45x1,5 | 60 | 65 | 11 | 6 | 2,5 | 0,14 |
| KMK 10 | M 50x1,5 | 65 | 70 | 13 | 6 | 2,5 | 0,18 |
| KMK 11 | M 55x2 | 69 | 75 | 13 | 7 | 3 | 0,19 |
| KMK 12 | M 60x2 | 74 | 80 | 13 | 7 | 3 | 0,20 |
| KMK 13 | M 65x2 | 79 | 85 | 14 | 7 | 3 | 0,24 |
| KMK 14 | M 70x2 | 85 | 92 | 14 | 8 | 3,5 | 0,28 |
| KMK 15 | M 75x2 | 91 | 98 | 14 | 8 | 3,5 | 0,33 |
| KMK 16 | M 80x2 | 98 | 105 | 18 | 8 | 3,5 | 0,45 |
| KMK 17 | M 85x2 | 103 | 110 | 18 | 8 | 3,5 | 0,52 |
| KMK 18 | M 90x2 | 112 | 120 | 18 | 10 | 4 | 0,65 |
| KMK 19 | M 95x2 | 117 | 125 | 20 | 10 | 4 | 0,76 |
| KMK 20 | M 100x2 | 122 | 130 | 20 | 10 | 4 | 0,80 |
